Martin Audio's revolutionary multi-cellular loudspeaker array - MLA technology is reshaping the way loudspeaker arrays are configured and controlled. It controls sound with unparalleled fidelity and powerful output capabilities, giving FOH engineers and audiences a richer experience. In the simplest terms, each MLA array has up to 144 individual drive units, each with its own on-board amplifier and DSP, which can be optimized by software to deliver sound to the listener, thus meeting the sonic targets required for any space. It remains the only system on the market that allows for the prioritization and corresponding optimization of multiple sonic targets. For example, the MLA not only produces a uniform sound field across the listener, but it can also contain a sound field, thus greatly reducing the impact of the room.

Speaker Type: Three-way Cellular Drive Unit, Active Array Component

Frequency Response: 52Hz-18kHz, ± 3dB

Maximum Sound Pressure Level: LF: 133dB (continuous), 139dB (peak); MF: 134dB (continuous), 140dB (peak); HF: 139dB (continuous), 145dB (peak)

Drive Unit: LF: 2 x 12 " (300mm)/3" (75mm) Voice Coil, Extra Long Stroke, Neodymium Magnetic Drive Unit , Trumpet Loaded Hybrid ® Bass

MF: 2 x 6.5 " (165mm)/2" (50mm) Voice Coil, Neodymium Magnetic Drive Unit, Trumpet Loaded

HF: 3 x 1 " (25mm) Outlet Neodymium Magnetic Compression Drive Unit, Trumpet Loaded

Rated Power: LF: 800W (AES), 3200W (Peak); MF: 400W (AES), 1600W (Peak); HF: 150W (AES), 600W (Peak)

Coverage Angle: Horizontal 90º (-6dB), 120º (-10dB); Vertical 7.5 °

minutes Frequency: 320Hz: 8th Order Linkwitz-Riley Filter, 4kHz: Vanishing Point ™ FIR Filter

Audio Input Interface: XLR Female Input, XLR Male Link Output

Analog Input Impedance: 20kΩ (balanced ground)

Maximum Analog Input Level: 6.15Vrms (+ 18dBu), Overvoltage Protection

Nominal System Gain: 28.5dB

AES/EBU Impedance: 110Ω (balanced), Receiver and Transmitter

Network Interface: 2 x IP68 Class 8-pin Interface, Fast Release

Network Protocol: U-NET

Amplifier Module Type: 6-Channel Class D Amplifier, Fixed Frequency

Amplifier Module Peak Output Power: 6000W

Amplifier Module Average Efficiency: 75%

Amplifier Module Cooling: 4 x Built-in Temperature Controlled Fan, 1 x Built-in Low Speed Blower, 1 x External Temperature Controlled Fan

Amplifier Module Maximum Ambient Temperature: Full Power Output 45 ° C (113 ° F)

Power Supply Type: Switch Mode, Fixed Frequency PFC

AC Input Operating Range: 100 - 240V~ AC, 50 - 60Hz

Power Factor: > 0.95

Nominal Power Consumption: 900W

Power Interface: 16A IEC309 (Ceeform) - IP44 Rating

Cabinet: Vertical trapezoid with 3.75 ° wall angle, multiple layers of birch and poplar construction

Topcoat: Black PU textured coating

Mesh cover: Black HEX porous steel mesh

Accessories: Proprietary rigging system; Handles on both sides; Protective rubber side panels with anti-skid pads; Wheel plates; Transport covers; Windshield

IP rating: IP 24

Dimensions (W × H × D): 1136mm x 372mm (376mm with wheel plate) x 675mm (825mm with wheel plate)

Weight (without wheel plate): 87.5kg (193 lbs)
